8CH WIFI NVR and camera
8CH WIFI NVR and camera
8CH WIFI NVR and camera
8CH WIFI NVR and camera

8CH WIFI NVR and camera

WIFI NVR and camera
* 8CH wifi nvr
* 10inch screen
* white color or black color for choice
wifi camera
* 8pcs 1.0mp or 1.3MP camera
* good quality
* built in wifi module
Produt Details Product Parameter

1-W










8CH WIFI NVR and camera

Feature:

DC TIMES 8CH WIFI NVR KIT security system is special designed with 7" or 10" LCD monitor to realize review your footage easily on the built-in monitor which saves you huge cost for a separate monitor.Instant email alerts only when motion is detected, catching every essential moment, save hard drive record storage
Excellent metal shell material ensure its waterproof(IP66) and vandal proof provide you a convenient and safe life.

  • Support 8ch simultaneous live viewing via smart phone.
  • All software are included in the CD, very easy remote network surveillance
  • Free Mobile App Eseenet allows you to watch your values anywhere anytime
  • Support viewing on Smartphones, tablets and Windows PC.
  • 720P 1.0 Mega Pixel HD Waterproof Wireless WIFI Security Camera System with 30m(100ft) IR Night Vision Distance and 30 to 350m(100ft to1150ft) WIFI Transmission Range;
  • Pls make sure the NVR connect well with network cable and all system is under a good web condition;
  • Connect IP cameras to your NVR first,and you can unplug the cable once the WiFi connection is well done.





2-W



wireless nvr specification

8CH

AV(audio/video) input

Operating System

Embedded Linux OS

Network Video

8CH

Network video input broadbank

20Mbps

AUdio Bitrate

64Kbps

AV (audio/video) output

HDMI input

1chresolution1024x7681366x7681440x900,1920x1080p

VGA output

1chresolution1024x7681366x768

1440x900,1920x1080p

AV CODEC Specification

Video Resolution

D1/720P

synch-playback

4CH

Video Control

Video/Capture mode

MaualTimeMotionAlarm

Playback mode

Real timeRoutineEvent

Backup

USB backup

Alarm

Alarm Input

4ch (optional)

Alarm Output

1ch (optional)

Hard Disk

Type

1*SATA interface

Max Capacity

4 TB at most for each

External Interface

Network Interface

1 adaptable RJ45 10M/100M, 1 WIFI interface

USB Interface

2 USB 2.0

Network Control

Protocol

UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up)
DHCP (Automatically obtain an IP address), etc

Others

Power Supply

DC12V3A

Power Consumption (W)

≤5WWithout HDD

Operate Temperature (°C)

-10~+55

Working Humidity (%) RH

10%~90%

Size

280mmW×230mmV×55mmH

Weightexcluding HDD

2.5Kg







IPC Specification720p CAMERA

Details

Sensor

1/4” Progressive Scan Sensor

Signal System

PAL/NTSC

Resolution

1280 x720 16 : 9 High Defination

Minimum illumination

Color: 0.1 Lux; B/W: 0.01 Lux

Shutter

1/25s to 1/25,000s

Lens

3.6mm

OSD

Date Time & Title

White Balance

Auto

Day&Night

Auto / Color / BW

3D-DNR

Auto

Mirror/Flip

On / Off

Frame Specification

Three Streaming at the Same Time:

H.264 1280x720@30fps or below

H.264 640x480@30fps or below

S/N

> 39.1 Db

Interface

RJ45 / WIFI 802.11b/g/n

General Specification

Anti-thunder Level

Standard IEC61000-4-5

Working Temperature/Humidity

-10 to +50 / 30% to 80% RH

Working Temperature/Humidity

-20 to +60 / 20% to 90% RH

Power Input

DC12V-1A

Power consumption

≤6W

Size

205(L)×70(W)×55 (H)mm

Weight

500g

Level of Protection

IP66



易视云






Package:



  • 1* NVR Recorder
  • 4*Wifi Bullet Camera
  • 2* Antenna for NVR
  • 1*Mouse for NVR
  • 1*Power Adapter for NVR
  • 4*Antenna for Cameras
  • 4*Power Adapter for Cameras
  • 1*Installing Accessories
  • 1*Manual
  • 1*CD
